Tapered Drilling
Tools
button bits
apered button bits are also know as cone button bits. The tapered button bits, inserted with tungsten carbide, connect with tapered rods by taper. According to button fixing processes, the tapered button bits are divided into thermal insert tapered bits and cold press tapered bits, which are widely used in mining, tunneling, anchoring and quarrying.
 |
|
||||||||||||||||||
|
Tapered button bits |
||||||||
|
LHS Part No. |
Diameter(mm) |
Dimension of Inner hole |
Full Length (without buttons)mm |
Gauge Buttons (No.* Diam.) |
Front Buttons (No.* Diam.) |
Angle |
Gauge Buttons (No.* Diam.) |
Front Buttons (No.* Diam.) |
|
ZQ32C10-1222B2 |
32 |
12°*φ22mm |
65 |
5*φ7mm |
2*φ7mm |
35° |
1*φ14mm |
2*φ4mm |
|
ZQ40S-725B2 |
40 |
7°*φ25mm |
65 |
4*φ9mm |
2*φ8mm |
35° |
1*φ5mm |
2*φ5mm |
|
ZQ41B-1122B2 |
41 |
11°*φ22mm |
50 |
3*φ9mm |
2*φ8mm |
35° |
1*φ5mm |
1*φ6mm |
|
ZQ45D1-1222B2 |
45 |
11°*φ22mm |
68 |
6*φ8mm |
2*φ8mm |
40° |
2*φ5mm |
2*φ5mm |
