Common Tapered Drilling Tools for Quarry

Quarry

Tapered Drilling Tools

LHS Part No.

Products

Description

11°Taper

ZQ34C-1122B2

Button Bit

　Diam.34mm, Parabolic Buttons, 5 Gauge Buttons, 11°Taper, Inner Hole Diam.22mm.

ZQ36C-1122B2

Button Bit

　Diam.36mm, Parabolic Buttons, 5 Gauge Buttons, 11°Taper, Inner Hole Diam.22mm.

ZQ38C1-1122B2

Button Bit

　Diam.38mm, Parabolic Buttons, 5 Gauge Buttons, 11°Taper, Inner Hole Diam.22mm.

ZQ40C-1122B2

Button Bit

　Diam.40mm, Parabolic Buttons, 5 Gauge Buttons, 11°Taper, Inner Hole Diam.22mm.

LG1122-800

Drill Rod

　Shank Hex.22*108mm, 11°Taper, Effective Length 800mm.

LG1122-1220

Drill Rod

　Shank Hex.22*108mm, 11°Taper, Effective Length 1220mm.

LG1122-1600

Drill Rod

　Shank Hex.22*108mm, 11°Taper, Effective Length 1600mm.

4°, 6°and 7°Taper

YX20-416

Blade Bit

　Chisel Bit, Diam.20mm, 4°Taper, Inner Hole Diam.16mm,

YX28E-620

Blade Bit

　Chisel Bit, Diam.28mm, 6°Taper, Inner Hole Diam.20mm,

SQ33H-722

Blade Bit

　Cross Bit, Diam.33mm, 7°Taper, Inner Hole Diam.22mm,

LG622-800

Drill Rod

　Shank Hex.22*108mm, 6°Taper, Effective Length 800mm.

LG725-1200

Drill Rod

　Shank Hex.22*108mm, 7°Taper, Effective Length 1200mm.

Integral Drill Rods and Plug-hole Drill Rods

TY40-800

Integral Drill Rod

　Carbide Diam.40mm,Shank Hex.22*108mm, Effective Length 800mm.

TY38-1600

Integral Drill Rod

　Carbide Diam.38mm,Shank Hex.22*108mm, Effective Length 1600mm.

TY26-200

Plug-hole Drill Rod

　Carbide Diam.26mm,Shank Hex.22*108mm, Effective Length 200mm.
